Gravity: Terminal Sensor Adapter V2.0
This is a universal sensor adapter that can be used by digital and analog input modules, converting sensors and other modules to the Gravity standard for easy connection to your projects.
In this latest version, DFRobot has added a 10K resistor between A & B and A & C respectively, so that youĀ don't need to wire an additional resistorĀ if your chosenĀ sensor requires a pull-up or pull-down resistor.
This terminal provides a much easier way to connect a switch or any modules that require a pull-up/down resistor prior to connection with your microcontroller.
Connection Example - DFRduino UNO R3
Specifications
- Voltage: +5 V
- Current: <1000mA
- Size: 22 x 34mm
Resources
- ProductĀ Wiki
- Schematic
Package Contents
- 1x Terminal Sensor Adapter V2.0
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Gravity: Terminal Sensor Adapter V2.0
Gravity: Terminal Sensor Adapter V2.0
This is a universal sensor adapter that can be used by digital and analog input modules, converting sensors and other modules to the Gravity standard for easy connection to your projects.
In this latest version, DFRobot has added a 10K resistor between A & B and A & C respectively, so that youĀ don't need to wire an additional resistorĀ if your chosenĀ sensor requires a pull-up or pull-down resistor.
This terminal provides a much easier way to connect a switch or any modules that require a pull-up/down resistor prior to connection with your microcontroller.
Connection Example - DFRduino UNO R3
Specifications
- Voltage: +5 V
- Current: <1000mA
- Size: 22 x 34mm
Resources
- ProductĀ Wiki
- Schematic
Package Contents
- 1x Terminal Sensor Adapter V2.0
